A Free Paint Color Matching API and Embeddable Widget

Updated
Philip Cameron
Save

If you build anything that touches paint (a design tool, a room visualizer, a retailer site, a home-improvement app), you have probably hit the same wall: a customer has a color from one brand and needs its equivalent in another. There has never been a clean, programmatic way to do that. We built the cross-brand matching engine behind Paint Color HQ, and we now expose it two ways: a one-line embeddable widget and a REST API. Both have a free tier, and the widget needs no signup and no key.

What It Does

Send a hex value and get back the closest paint colors across 13 brands (Sherwin-Williams, Benjamin Moore, Behr, PPG, Valspar, Farrow & Ball, Dunn-Edwards, and more) ranked by how close each match actually reads to the eye. Matches are scored with CIEDE2000 (Delta E 2000), the industry standard for perceptual color difference, over a database of 26,000+ colors. Results are labeled Nearly identical, Very similar, or Visible difference.

The Free Widget: One Line of HTML

If you do not want to write code, drop the matcher straight into any page. Your visitors pick a color and instantly see the closest match in every brand, no key, no signup. Keep the small credit line and it is free.

<iframe src="https://www.paintcolorhq.com/embed/match"
  width="100%" height="480" loading="lazy"
  style="border:0;border-radius:12px;max-width:600px"
  title="Cross-brand paint color matcher"></iframe>

Grab it on the embeddable widget page.

The API: Free Endpoint

For programmatic use, call the endpoint directly. It is CORS-open and cached at the edge, so it is fast and works from the browser or your backend.

GET https://www.paintcolorhq.com/api/color-match?hex=7F9B8E

A trimmed response:

{
  "matches": [
    {
      "name": "Comfort Gray",
      "hex": "#9C9B8E",
      "brandName": "Sherwin-Williams",
      "colorSlug": "comfort-gray-6205",
      "colorNumber": "6205",
      "deltaE": 1.84
    }
  ]
}

Parameters: hex (required, 6-digit, with or without #), brand (optional: restrict to one brand such as benjamin-moore), and limit (optional). Full reference and live examples are on the API docs page.

The Paid Tier, for Heavier Use

The free endpoint covers most needs. Free use requires a visible link to PaintColorHQ (for example, “Cross-brand paint matching by PaintColorHQ”) on the page that shows the results. For production integrations, the paid tier on RapidAPI adds up to 50 results per call, batch lookups (several hex values at once), and per-match color-science fields (LAB, RGB, undertone, LRV, and color family) useful for palette engines and lighting-aware design tools. RapidAPI handles keys, rate limits, and billing, so you can start on the free plan and scale without touching our infrastructure. See the listing on RapidAPI.

Why Cross-Brand Matching Is the Hard Part

Plenty of color APIs generate palettes, convert hex to RGB, or name a single color. Almost none answer the question that actually comes up in paint workflows: what is the nearest equivalent to this exact color in a brand my store carries? That is a data problem, not a formula problem. CIEDE2000 is public math; the moat is a maintained, normalized catalog of 26,000+ colors across 13 brands, kept current as palettes change, with one canonical match per brand instead of a noisy list. The consumer match tools that exist are web pages, not endpoints.

How the Matching Works

Each color is converted to CIELAB, candidates within range are scored against your input with CIEDE2000, and the closest equivalent per brand is surfaced. The full pipeline, thresholds, and known limitations are documented on our methodology page. As with any color match, the honest advice is to confirm a final choice with a physical sample before buying gallons. You can also explore matches by hand in the color comparison tool, build a scheme in the palette generator, browse any brand color chart, or read how we map Sherwin-Williams alternatives to Benjamin Moore.

Frequently asked questions

Is the paint color matching API really free?
Yes. The embeddable widget is free with a small attribution link, and the API has a free tier with no key required for the open endpoint. Free API use requires a visible link to PaintColorHQ on the page that shows the results. Paid RapidAPI plans add higher volume and extra color-science fields.
How accurate are the cross-brand matches?
Matches are scored with CIEDE2000 (Delta E 2000), the industry standard for perceptual color difference. Light and mid-tone colors match very closely; deep, saturated colors are harder to reproduce across brands' colorant systems, so we show closeness in plain language and recommend confirming with a physical sample.
Can I use the paint color API commercially?
Yes, within the plan limits. The widget and the free API endpoint are free with a visible credit link to PaintColorHQ, and the API's commercial terms scale with the RapidAPI tier you choose.
